| FIFTH
WHEEL HEIGHT |
1350 mm |
| LOADING
PLATFORM HEIGHT |
1000 mm (Loaded) |
| OVERALL
LENGTH |
16920 mm |
| OVERALL
WIDTH |
3000 mm |
| LOADING
PLATFORM LENGT |
12600 mm |
| GOOSENECK
LENGTH |
4320 mm |
| AXLE
GROUP CAPACITY |
70.000 kg |
| KING PIN
CAPACITY |
18.000 kg |
| TOTAL
GCW (CAPACITY) |
88.000 kg |
| CHASSIS
CONSTRUCTION |
SERIN chassis suitable for 98/91
EEC standards made from high graded steel with “I” profile shape, produced
with atomized submerged arc welding system. |
| BRAKE
SYSTEM |
Brake system suitable for 71/320
EC and 2002/78 EC standards. Automatic load sense valve RSS (corner
stabilizer). |
| AXLE |
SERIN Brand 5 x 14 ton capacity,
Mechanical suspension |
| TIRES
& RIMS |
20+1 PCS tire with size 295 60 R
22,5 |
| ELECTRICAL
SYSTEM |
Electrical system suitable for
76/756/EEC, 2007/35 EC and ADR standards. 2 x 7 pole plugs, 1 x 15 pole plug
suitable for all type truck tractors LED system. Front and side warning
lights. |
| LANDING
GEARS |
JOST Brand, 24 ton carrying
capacity, double speed mechanical landing gear. |
| REAR
LOADING RAMP |
Sliding Hydraulic Ramp, ramp
overall dimension 3130 mm |
| BASE
PLATE |
68 mm hard wood floor covering,
gooseneck covered with checkered plate |
| WATER
TANK |
60 liter stainless steel water
tank. |
| TOOL
BOX |
2 PCS with dimensions
1500*500*400 mm |
| SIDE
PROTECTIVE BARS |
Impact-resistant side bicycle
protective bar suitable for 70/156 EEC standards |
| LASHING
HOOKS AND LASHING POINTS |
2*11 load lashing hook suitable
for safe cargo transport. |
| WIDENING
BRACKETS |
2 x 9 PCS widening brackets with
250 + 250 mm dimension |
| GOOSENECK
SIDE COVER |
Aluminum side cover with 350 mm
height |
| DISTANCE
BETWEEN AXLES |
1380 mm |
